AUTOMEC-COASTONE C12 C- Frame- Small Press Brake
Have one to sell?
ConditionNew
New
The small CoastOne press brakes are great machines for bending small parts fast and accurately (0.00008”). They can be easily transported around a shop with a forklift. Customers can free up capacity on larger machines with these energy efficient, quiet, work-horses. If you need an extremely accurate, repeatable and fast machine, this is the undoubtably the right choice for your application.
Tonnage 50 ton
Max. bending length 51”/4.25’
Distance between frames 49.0”
Throat depth 5.90”
Open height max 19.68”
Open height min 9.84”
Y axis strokelength 9.84”
Y axis speed, approach/return 236 IPM
Y axis speed, forming max 23.6 IPM
Y axisaccuracy +/- 0.000079”
X axisstroke 23.62”
X axisspeed 19.69 IPS
X axisaccuracy +/- 0.001”
R axisstroke 7.87”
R axisspeed 236 IPM
Motor power 13.4 HP
Machine weight 6,173 lbs.
Machine width, foot to foot 76”
Machine width, frame 51”
Machine depth 61”
Machine height 89.76”
Control Omron
Servo motor Yaskawa/ Panasonic
Ball screws 2
