AUTOMEC-COASTONE G40 O-Frame- Large Press Brake
Have one to sell?
ConditionNew
New
The large CoastOne press brakes (G-Series) are unique because we do not convert them to a servo-hydraulic system (most competitors). Our machines utilize ball screws and servo motors (up to 6 screws and 6 servos). With this technology, our machines offer “automatic crowning.” Each axis of the upper beam works simultaneously as a crowning axis. This way, the upper beam can be CNC deflected. Each axis works separately and independently without making compromises. The press brakes offer 0.00008” accuracy and repeatability!
Tonnage 150 ton
Max. bending length 160.6”/13’
Distance between frames 165.4”
Throat depth n/a
Open height max 23.6”
Open height min 12.60”
Y axis strokelength 11’
Y axis speed, approach/return 189 IPM
Y axis speed, forming max 23.6 IPM
Y axisaccuracy +/- 0.000079”
X axisstroke 23.6”
X axisspeed 19.70 IPS
X axisaccuracy +/- 0.001”
R axisstroke 7.9”
R axisspeed 236 IPM
Motor power 40 HP
Machine weight 15,432 lb.
Machine width, foot to foot
Machine width, frame 197”
Machine depth 78”
Machine height 116”
Control Omron
Servo motor Yaskawa/ Panasonic
Ball screws 6
