Machine size L5550 x W4500 x H3565 mm
Print envelope Up to L1800 x W1200 x H1500 mm3 (configuration dependent)
Control system KUKA KRC5 with Siemens PLC
Shielding management PMAX: Local shielding + *global shielding
GMAX: Local / *Global fume management system
WAAM variants
Plasma Transferred Arc (PTA) or *Dual Wire Plasma Transferred Arc (PMAX)
Gas Metal Arc (GMA) or *Cold-Wire GMA (GMAX)
Welding power sources
PMAX: EWM Tetrix 552 Synergic Plasma
GMAX: FRONIUS TPSI - *FRONIUS iWAVE
Axes 6 (robotic arm) + 2 (servopositioner)
Materials
PMAX: Titanium alloys, stainless steel, nickel alloys, and others
*Multi-material functionality
GMAX: Alloys of iron, aluminum, nickel, copper, and others
*Multi-material functionality
Rotational table 500 kg payload (upgradable to 750kg payload)
Sensors Process camera, Weld sensors
*Pyrometer, *IR camera, *Shapetech
Controls
Manual wire position control
*Auto wire control using images based AI
*Auto arc start with interlayer temperature control
*Auto layer height correction
RoboWAAM® - GMA/GMAX specification
GMA is a process where an electric arc forms between a continuously fed wire electrode and the
substrate, that melts both, allowing continuous deposition of metallic materials whilst applying shielding gas protects the freshly deposited bead.
PTA (Plasma Transferred Arc) is a process where a plasma arc formed between a non-consumable
tungsten electrode and the substrate, it melts the filler wire, enabling precise deposition of material, while
the shielding gas protects the molten pool and ensures high-quality metallurgical bonding. The process
runs on DC (direct current), making it simple to control without complex waveforms; the wire is melted in
the low-energy part of the arc, resulting in a clean, spatter-free process with minimal fume.
RoboWAAM® PTA/PMAX - GMA/GMAX specification:
WAAM, RoboWAAM, MiniWAAM, WAAMPlanner and WAAMCtrl are registered trademarks of WAAM3D Ltd. | Last updated: November 2025
Technical specification Details and optional upgrades (marked with *)
Machine size L5550 x W4500 x H3565 mm
Print envelope Up to L1800 x W1200 x H1500 mm3 (configuration dependent)
Control system KUKA KRC5 with Siemens PLC
Shielding management PMAX: Local shielding + *global shielding
GMAX: Local / *Global fume management system
WAAM variants
Plasma Transferred Arc (PTA) or *Dual Wire Plasma Transferred Arc (PMAX)
Gas Metal Arc (GMA) or *Cold-Wire GMA (GMAX)
Welding power sources
PMAX: EWM Tetrix 552 Synergic Plasma
GMAX: FRONIUS TPSI - *FRONIUS iWAVE
Axes 6 (robotic arm) + 2 (servopositioner)
Materials
PMAX: Titanium alloys, stainless steel, nickel alloys, and others
*Multi-material functionality
GMAX: Alloys of iron, aluminum, nickel, copper, and others
*Multi-material functionality
Rotational table 500 kg payload (upgradable to 750kg payload)
Sensors Process camera, Weld sensors
*Pyrometer, *IR camera, *Shapetech
Controls
Manual wire position control
*Auto wire control using images based AI
*Auto arc start with interlayer temperature control
*Auto layer height correction
