2015 Stratasys Connex 3 OBJET 500

Key Specifications
Build Volume (XYZ)
255 × 252 × 200 mm (10.0 × 9.9 × 7.9 in.)
Layer Thickness
16 μm (0.0006 in.) – High Quality mode
30 μm (0.001 in.) – Digital Material / High Speed mode
Resolution
X-axis: 600 dpi
Y-axis: 600 dpi
Z-axis: 1600 dpi
Accuracy
Up to 200 μm for full model size (rigid materials; geometry, orientation, and parameters dependent)
Model Materials
• Rigid Opaque (Vero family: VeroWhitePlus, VeroBlackPlus, VeroGray, VeroBlue, VeroCyan, VeroMagenta, VeroYellow, VeroPureWhite, etc.)
• Rubber-like (Agilus30, TangoPlus, TangoBlackPlus, TangoBlack, TangoGray)
• Transparent (VeroClear, RGD720)
• Simulated Polypropylene (Rigur, Durus)
• High Temperature & Bio-compatible materials
Digital Materials
Over 1,000 material combinations
Maximum 82 materials per part (including vibrant colors, translucent tints, rubber-like blends in various Shore A values, Digital ABS Plus™, etc.)
Support Materials
SUP705 (WaterJet removable)
SUP706 (soluble)
Build Modes
High Quality (16 μm)
Digital Material (30 μm)
High Speed (30 μm)
System Dimensions (W×D×H)
870 × 1,200 × 735 mm (34.2 × 47.2 × 29 in.)
System Weight
Printer: 264 kg (581 lbs.)
Material Cabinet: 76 kg (168 lbs.)
Power Requirements
100–240 VAC, 50/60 Hz, 1.5 kW (single phase)
Workstation Compatibility
Windows 7 / 8 / 10 (32/64-bit)
Network Connectivity
LAN – TCP/IP
