BODOR P4 60KW

P4 Laser Power
"Bodor laser P4 model 13.12' X 6.56' table size fiber laser cutting machine.
BodorThinker Control system.
Bodor Maxphotonics.
Precitec Laser head." 60kw
Dust collector (Laser fume filter) 1 SET
37kw Air Compressor 1 SET
One years on-site service 1 SET Included
Freight&Tariff Included
Installation & Training Cost Included
Lead time IN STOCK
Payment Terms "30% deposit upon receipt of PO.
70% prior to shipment.
"
Warranty 5 years laser head, 5 years laser source, 5 years control system.
Water Chiller/Transformer included.
Basic Parameter
Working area 4000mm*2000mm (13.12′*6.56′)"
Max. acceleration 4G
Max. linkage speed 200m/min (7,874 inch/min)
Configuration
Laser source Bodor Maxphotonics
Laser head "
Precitec Laser head (Germany)."
Machine bed Tenon and mortise structure bed
Gantry structure Stretched Aluminum gantry
X-axis、Y-axis、Z-axis Servo motor and driver Bodor
Linear Rails Bodor
Rack Bodor
Protective Enclosure Yes
Enhanced-partition Dust Removal Yes
Control system Bodor Thinker
Display size 21.5 inches touch screen
Door-open Protection Yes
Intelligent alarm Yes
Water Chiller Yes
Dust removal Centrifugal fan
File format IGS、DXF、G Code、DWG
Transformer Yes
Power Requirements 220V/440V/480V 60HZ 3PHASE (Up to Clients Power Requirement)
Whole machine power/current/Average Power with 12kW sourceat 380V 59.8KW/113.6A
Intelligent function
One-click processing Yes
Automatic nozzle changer Yes
One-second edge search Yes
Remnant Typesetting Yes
Laser head high pressure filter Yes
intellgent over-heat adaptation Yes
Intelligent anti-shake Yes
Bodor lightning perforation Yes
Cutting Parameter AutoMatch Yes
Touchscreen Display Yes
Automatic nozzle cleaning Yes
Air pressure intelligent control Yes
Automatic adjustment of cutting gas pressure "O2、N2、air
"
Auto-focus of laser head Yes
Laser cutting technology expert database Yes
Ergonomic Remote Control (Bodor Mango®) Yes
Active anti-collision function Yes
Mineral casting anti burning Yes
High quality Cutting Expert Database Yes
Behind table Visual collision detection Yes
Gas-saving steady flow nozzle Yes
Intelligent maintenance reminder Yes
WIFI internet connection Yes
Bodor Cloud service Yes
Performance
Table load bearing 2510kg/5533.6lb
Requirements for sheet Plate thickness≥0.8mm（0.0315″)
Machine overall dimensions "11599mm*3380mm*2718mm
(38.05′*11.09′*8.92′)"
Overall weight 9090kg/20040lb
Z axis travel 370mm(14.57″)
Positioning accuracy ±0.03mm/m(0.00118″)
Repositioning accuracy ±0.02mm(0.00787″)
Φ30mm roundness ≤0.15mm(0.00591″)
□30mm adjacent side dimension difference ≤0.06mm(0.00236″)
□190mm adjacent side dimension difference ≤0.15mm(0.00591″)
□190mm diagonal size difference ≤0.20mm(0.00787″)
