BODOR P6 12KW 21.33' x 8.2’ fiber laser

P6 Laser Power
"Bodor Laser P6 21.33'x8.2’ fiber laser cutting
machine.
BodorThinker Control system.
Bodor Maxphotonics.
Bodor Laser head." 12kw
37kw Air Compressor 1 SET Included
Dust Collector 1 SET Included
First year on site service 1 SET Included
Freight&Tariff Included
Installation & Training Cost Included
Lead time 3-4 monthes
Payment Terms "30% deposit upon receipt of PO.
60% prior to shipment.
Remaining 10% in 7 days after installation and training."
Warranty "5 years laser head, 5 years laser source, 5 years control system.
3-year bumper-to-bumper warranty."
Water ChilleA17:C70
Basic Parameter
Working area 6500mm*2500mm(21.33'x8.2’)
Max. acceleration 2.8G
Max. linkage speed 200m/min (7,874 inch/min)
Configuration
Laser source Bodor Maxphotonics
Laser head "Bodor
"
Machine bed Tenon and mortise structure bed
Gantry structure Stretched Aluminum gantry
X-axis、Y-axis、Z-axis Servo motor and driver Bodor
Linear Rails Bodor
Rack Bodor
Protective Enclosure Yes
Enhanced-partition Dust Removal Yes
Control system Bodor Thinker
Display size 21.5 inches touch screen
Door-open Protection Yes
Intelligent alarm Yes
Water Chiller Yes
Dust removal Centrifugal fan
File format IGS、DXF、G Code、DWG
Transformer Yes
Power Requirements 220V/440V/480V 60HZ 3PHASE (Up to Clients Power Requirement)
Whole machine power/current/Average Power with 12kW sourceat 380V 59.8KW/113.6A
Intelligent function
One-click processing Yes
Automatic nozzle changer Yes
Laser head high pressure filter Yes
intellgent over-heat adaptation Yes
Intelligent anti-shake Yes
Bodor lightning perforation Yes
Cutting Parameter AutoMatch Yes
Touchscreen Display Yes
Automatic nozzle cleaning Yes
Automatic nozzle changer Yes
Air pressure intelligent control Yes
Automatic adjustment of cutting gas pressure Yes
Auto-focus of laser head Yes
Laser cutting technology expert database Yes
Ergonomic Remote Control (Bodor Mango®) Yes
Active anti-collision function Yes
Mineral casting anti burning Yes
High quality Cutting Expert Database Yes
Behind table Visual collision detection Yes
Gas-saving steady flow nozzle Yes
Intelligent maintenance reminder Yes
WIFI internet connection Yes
Bodor Cloud service Yes
Performance
Table load bearing 7653kg
Requirements for sheet Plate thickness≥0.8mm（0.0315″)
Machine overall dimensions 16888mm*3872mm*2519mm (55.41′*12.7′*8.26′)
Overall weight 15000kg (33069lb)
Z axis travel 370mm(14.57″)
Positioning accuracy ±0.05mm/m(0.00197″)
Repositioning accuracy ±0.03mm(0.00118″)
Φ30mm roundness ≤0.15mm(0.00591″)
□30mm adjacent side dimension difference ≤0.06mm(0.00236″)
□190mm adjacent side dimension difference ≤0.15mm(0.00591″)
□190mm diagonal size difference ≤0.20mm(0.00787″)
