HPB 31175 3 Axes CNC Press Brake 10’x190 ton
Have one to sell?
ConditionNew
1 available
New
The HPB is perfect for complex, sensitive single or multiple bends at high speed. This machine is among the highest-rated for increasing productivity and lowering costs, thanks to a user-friendly CNC controller and low-cost hydraulic maintenance. It provides greater production capacity and eliminates wasted time during production. High-quality, repeatable bending is achieved with synchronized cylinders and valves. Automatic axis referencing and calibration occur when the machine is turned on.
Specifications Bending Length 3100mm (122”)
Bending Power 175 tons (192 US tons)
Between Columns 2600mm (102”)
Ram Rapid Speed 180 mm/sec (7”/sec.)
Ram Working Speed 10 mm/sec (0.4”/sec.)
Ram Return Speed 135 mm/sec (5.3”/sec.)
Travel In Backgauge Axis 800 mm (31")
Speed of Backgauge Axis 500 mm/m (19.7"/m)
Backgauge Finger Blocks 2
Sheet Support Arms 2
Oil Capacity 200 liters (52 Gal)
Motor Power 15 kW (20 Hp)
Stroke 275 mm (10.8")
Daylight 550 mm (21.6")
Throat Depth 410 mm (16")
Table Height 900 mm (35")
Table Width 90 mm (3.5")
Dimensions 4250x2800x2150 mm(167x110x85")
Weight 9450kg (20,830 lbs)
Standard configuration includes adjustable and sliding front support arms. Top and bottom tools are surface-hardened by special treatment. Promecam quick-clamping system. Delem DA-53T CNC-controlled, strong 800 mm back gauge. 410 mm (16') throat depth. 2-piece back gauge fingers. Scales in metric and inches. Foot pedal is CE-compliant and suitable for single and multiple bends. 2 photocells are positioned facing each other for rear and side guards. Covers for cylinders and top beam.
Parts & Labor Warranty: 2 years (up to 4,000 hours)
Payment: 30% at order, 60% prior to shipment, 10% on receipt. Financing available on request.
