BODOR K3 30FT 12KW TUBE LASER
Have one to sell?
ConditionNew
1 available
New
Discover precision with the new BODOR K3 Laser Cutter. With 12 kW of power and a cutting area of 6 x 0.36 x 0.35, it's ideal for your next project. Enhance your operations with this state-of-the-art machine.
****Lead time for K3 12 kW: 4-4.5 months*****
Tube cross-sectional shapes: Round, square, rectangular, oval, rounded rectangular, angle steel, channel steel, and other tubes
Tube size range
Round tube: Φ0.98-Φ14.01 in
Square tube: Φ0.98-Φ14.01 in
Rectangular tube:
14.01 in ≥ side length ≥ 0.98 in
Maximum machinable tube length: 30 ft
K3 Laser Power Price
"K3 30ft tube laser
BodorThinker Control system. BodorPower Laser source. BodorGenius Laser head." 12kw
K-Loader 1 Set Included
Dust Collector 1 Set Included
Air compressor 1 Set Included
One year onsite service 1 Set Included
Freight&Tariff Included
Installation & Training Cost Included
Payment Terms "30% down payment required to initiate production.
60% before shipping.
10% due within 7 days after installation and training is completed.
Warranty: 5 years laser head, 5 years laser source, 5 years control system.
Water Chiller/Transformer included.
Discover precision with the new BODOR K3 Laser Cutter. With 12 kW of power and a cutting area of 6 x 0.36 x 0.35, it's ideal for your next project. Enhance your operations with this state-of-the-art machine.
****Lead time for K3 12 kW: 4-4.5 months*****
Tube cross-sectional shapes: Round, square, rectangular, oval, rounded rectangular, angle steel, channel steel, and other tubes
Tube size range
Round tube: Φ0.98-Φ14.01 in
Square tube: Φ0.98-Φ14.01 in
Rectangular tube:
14.01 in ≥ side length ≥ 0.98 in
Maximum machinable tube length: 30 ft
Imperial
| Length | 31.32' |
| Width | 7.66' |
| Height | 9.35' |
| Cutting area X | 6 m |
| Cutting area Y | 0.4 m |
| Cutting area Z | 0.4 m |
| Bilateral repeatability of positioning of one axis R (ISO 230-2:2014) | 0.00118 in |
| Averaged, bilateral position deviation of one axis M (ISO 230-2:2014) | 0.002" |
| Max. workpiece weight | 1102.31 lb |
| Machine weight | 9612.11 lb |
| Power | 1000 w |
| Control | CNC |
| Dimensions | 31.32 ft × 7.66 ft × 9.35 ft |
| Weight | 9612.11 |
K3 Laser Power Price
"K3 30ft tube laser
BodorThinker Control system. BodorPower Laser source. BodorGenius Laser head." 12kw
K-Loader 1 Set Included
Dust Collector 1 Set Included
Air compressor 1 Set Included
One year onsite service 1 Set Included
Freight&Tariff Included
Installation & Training Cost Included
Payment Terms "30% down payment required to initiate production.
60% before shipping.
10% due within 7 days after installation and training is completed.
Warranty: 5 years laser head, 5 years laser source, 5 years control system.
Water Chiller/Transformer included.
